PM42S-220-RC

PM42S-220-RC

Image is for reference,
please contact us to get the real picture

Part No :

PM42S-220-RC

Manufacturer
J.W. Miller / Bourns
Description
FIXED IND 22UH 880MA 300MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Jul 20 - Jul 24 2025
DataSheet
PM42S-220-RC PDF
Availability
0 pieces
Unit Price
$0.70400

Current price of PM42S-220-RC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PM42S-220-RC Specifications
Type Description
Series:PM42S
Package:Tape & Reel (TR)
Part Status:Active
Type:Wirewound
Material - Core:Ferrite
Inductance:22 µH
Tolerance:±30%
Current Rating (Amps):880 mA
Current - Saturation (Isat):650mA
Shielding:Shielded
DC Resistance (DCR):300mOhm Max
Q @ Freq:7 @ 2.52MHz
Frequency - Self Resonant:29MHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max):0.118" (3.00mm)
