Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of TYA30154R7M-10 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | TYA3015 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Wirewound |
Material - Core: | Metal |
Inductance: | 4.7 µH |
Tolerance: | ±20% |
Current Rating (Amps): | 1.7 A |
Current - Saturation (Isat): | 2.5A |
Shielding: | Shielded |
DC Resistance (DCR): | 185mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | AEC-Q200 |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 1 MHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | - |
Size / Dimension: | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
Height - Seated (Max): | 0.065" (1.65mm) |
