Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of BWCS001610087N5G00 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | BWCS |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Wirewound |
Material - Core: | Ceramic |
Inductance: | 7.5 nH |
Tolerance: | ±2% |
Current Rating (Amps): | 700 mA |
Current - Saturation (Isat): | - |
Shielding: | Unshielded |
DC Resistance (DCR): | 106mOhm Max |
Q @ Freq: | 28 @ 250MHz |
Frequency - Self Resonant: | 4.8GHz |
Ratings: | - |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 250 MHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | 0603 (1608 Metric) |
Supplier Device Package: | 0603 |
Size / Dimension: | 0.063" L x 0.040" W (1.60mm x 1.02mm) |
Height - Seated (Max): | 0.040" (1.02mm) |
