Type | Description |
---|---|
Series: | FIT |
Package: | Bulk |
Part Status: | Active |
Type: | Toroidal |
Material - Core: | Iron Powder |
Inductance: | 21.65 µH |
Tolerance: | - |
Current Rating (Amps): | 4.8 A |
Current - Saturation (Isat): | - |
Shielding: | Unshielded |
DC Resistance (DCR): | 29.2mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | - |
Operating Temperature: | -40°C ~ 85°C |
Inductance Frequency - Test: | 10 kHz |
Features: | - |
Mounting Type: | Through Hole |
Package / Case: | Radial, Vertical (Open) |
Supplier Device Package: | - |
Size / Dimension: | 0.700" L x 0.475" W (17.78mm x 12.07mm) |
Height - Seated (Max): | 0.750" (19.05mm) |
FIXED IND 21.65UH 4.8A 29.2 MOHM
