Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of MPL-SE4030-4R7 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | MPL-SE |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | - |
Material - Core: | - |
Inductance: | 4.7 µH |
Tolerance: | - |
Current Rating (Amps): | 2.6 A |
Current - Saturation (Isat): | 3.7A |
Shielding: | Shielded |
DC Resistance (DCR): | 63mOhm |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | - |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 100 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard, 2 Lead |
Supplier Device Package: | - |
Size / Dimension: | 0.157" L x 0.157" W (4.00mm x 4.00mm) |
Height - Seated (Max): | 0.118" (3.00mm) |
