Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of ECS-MPI4040R3-4R7-R is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | ECS-MPI4040 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | - |
Material - Core: | - |
Inductance: | 4.7 µH |
Tolerance: | ±20% |
Current Rating (Amps): | 2.3 A |
Current - Saturation (Isat): | 4.8A |
Shielding: | Shielded |
DC Resistance (DCR): | 92mOhm |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | AEC-Q200 |
Operating Temperature: | -55°C ~ 125°C |
Inductance Frequency - Test: | 100 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | - |
Size / Dimension: | 0.175" L x 0.160" W (4.45mm x 4.06mm) |
Height - Seated (Max): | 0.073" (1.85mm) |
