Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of CD5.243 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | DIMENSION CD (92 ~ 120W) |
Package: | Bulk |
Part Status: | Active |
Type: | Enclosed |
Voltage - Input (Min): | 10.8V |
Voltage - Input (Max): | 16.2V |
Number of Outputs: | 1 |
Voltage - Output 1: | 24V |
Voltage - Output 2: | - |
Voltage - Output 3: | - |
Voltage - Output 4: | - |
Current - Output (Max): | 4A |
Power (Watts): | 84W |
Voltage - Isolation: | - |
Applications: | ITE (Commercial) |
Efficiency: | 87.7% |
Operating Temperature: | -25°C ~ 70°C (With Derating) |
Mounting Type: | DIN Rail |
Size / Dimension: | 4.02" L x 1.26" W x 4.88" H (102.0mm x 32.0mm x 124.0mm) |
Approval Agency: | ABS, ATEX, CSA, DNV GL, EAC, IEC, IECEx, UL |
Standard Number: | Class I Div 2; 508; 60950-1 |
