Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 902-0060-000 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | * |
Package: | Box |
Part Status: | Active |
Type: | DC Motor |
Function: | Servomotor |
Motor Type: | Brushed |
Voltage - Rated: | 12VDC |
RPM: | 63 RPM |
Torque - Rated (oz-in / mNm): | - |
Power - Rated: | - |
Encoder Type: | Absolute |
Size / Dimension: | Rectangular - 2.405" x 1.582" (61.10mm x 40.20mm) |
Diameter - Shaft: | - |
Length - Shaft and Bearing: | - |
Mounting Hole Spacing: | - |
Termination Style: | Connector |
Features: | Integrated Controller |
Gear Reduction Ratio: | 200 |
Torque - Max Momentary (oz-in / mNm): | 849.8 / 6000 |
Operating Temperature: | -5°C ~ 80°C |
