Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of PTS125SM85-2 LFS is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | PTS125 |
Package: | Bulk |
Part Status: | Active |
Circuit: | SPST-NO |
Switch Function: | Off-Mom |
Contact Rating @ Voltage: | 0.05A @ 12VDC |
Actuator Type: | Standard |
Mounting Type: | Through Hole |
Actuator Height off PCB, Vertical: | 8.50mm |
Actuator Length, Right Angle: | - |
Actuator Orientation: | Top Actuated |
Termination Style: | PC Pin |
Outline: | 12.00mm x 12.00mm |
Illumination: | Non-Illuminated |
Illumination Type, Color: | - |
Illumination Voltage (Nominal): | - |
Operating Force: | 180gf |
Ingress Protection: | - |
Features: | - |
Operating Temperature: | -40°C ~ 60°C |
