Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of CI2503P1V00-LF is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | CI25 |
Package: | Bag |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.098" (2.50mm) |
Number of Positions: | 3 |
Number of Rows: | 1 |
Row Spacing - Mating: | - |
Number of Positions Loaded: | All |
Style: | Board to Cable/Wire |
Shrouding: | Shrouded - 4 Wall |
Mounting Type: | Through Hole |
Termination: | Solder |
Fastening Type: | Detent Lock |
Contact Length - Mating: | - |
Contact Length - Post: | 0.134" (3.40mm) |
Overall Contact Length: | 0.350" (8.89mm) |
Insulation Height: | 0.232" (5.90mm) |
Contact Shape: | Circular |
Contact Finish - Mating: | Tin |
Contact Finish Thickness - Mating: | 120.0µin (3.05µm) |
Contact Finish - Post: | Tin |
Contact Material: | Brass |
Insulation Material: | Polyamide (PA46), Nylon 4/6 |
Features: | - |
Operating Temperature: | -25°C ~ 85°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-0 |
Insulation Color: | Natural |
Current Rating (Amps): | 3A |
Voltage Rating: | 50VAC |
