Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of CI0105M1VR0-NH is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | CI01 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.079" (2.00mm) |
Number of Positions: | 5 |
Number of Rows: | 1 |
Row Spacing - Mating: | - |
Number of Positions Loaded: | All |
Style: | Board to Cable/Wire |
Shrouding: | Shrouded - 4 Wall |
Mounting Type: | Surface Mount |
Termination: | Solder |
Fastening Type: | Detent Lock |
Contact Length - Mating: | 0.142" (3.61mm) |
Contact Length - Post: | - |
Overall Contact Length: | - |
Insulation Height: | 0.263" (6.67mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Tin |
Contact Finish Thickness - Mating: | 120.0µin (3.05µm) |
Contact Finish - Post: | Tin |
Contact Material: | Brass |
Insulation Material: | Polyamide (PA6T), Nylon 6T, Halogen Free |
Features: | Pick and Place, Solder Retention |
Operating Temperature: | -25°C ~ 105°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-0 |
Insulation Color: | Natural |
Current Rating (Amps): | 2A |
Voltage Rating: | 250VAC/DC |
