Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of STSHC-205-D-03-G-LF is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | STSHC-2 |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.079" (2.00mm) |
Number of Positions: | 10 |
Number of Rows: | 2 |
Row Spacing - Mating: | 0.079" (2.00mm) |
Number of Positions Loaded: | All |
Style: | Board to Board |
Shrouding: | Shrouded - 4 Wall |
Mounting Type: | Through Hole |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Length - Mating: | 0.120" (3.05mm) |
Contact Length - Post: | - |
Overall Contact Length: | 0.323" (8.20mm) |
Insulation Height: | 0.189" (4.80mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Gold |
Contact Finish Thickness - Mating: | 10.0µin (0.25µm) |
Contact Finish - Post: | Gold |
Contact Material: | Phosphor Bronze |
Insulation Material: | Liquid Crystal Polymer (LCP) |
Features: | - |
Operating Temperature: | -40°C ~ 105°C |
Ingress Protection: | - |
Material Flammability Rating: | - |
Insulation Color: | Black |
Current Rating (Amps): | 2A |
Voltage Rating: | - |
