Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of TSHSCM-803-D-06-020-T-LF is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | TSHSCM-8-V |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.031" (0.80mm) |
Number of Positions: | 6 |
Number of Rows: | 2 |
Row Spacing - Mating: | 0.047" (1.20mm) |
Number of Positions Loaded: | All |
Style: | Board to Board |
Shrouding: | Shrouded - 4 Wall |
Mounting Type: | Surface Mount |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Length - Mating: | 0.020" (0.51mm) |
Contact Length - Post: | - |
Overall Contact Length: | - |
Insulation Height: | 0.039" (1.00mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Tin |
Contact Finish Thickness - Mating: | - |
Contact Finish - Post: | Tin |
Contact Material: | Phosphor Bronze |
Insulation Material: | Polyamide (PA6T), Nylon 6T |
Features: | - |
Operating Temperature: | -40°C ~ 105°C |
Ingress Protection: | - |
Material Flammability Rating: | - |
Insulation Color: | Black |
Current Rating (Amps): | 500mA |
Voltage Rating: | - |
