Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of TLP621-2X is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | - |
Package: | Tube |
Part Status: | Active |
Number of Channels: | 2 |
Voltage - Isolation: | 5300Vrms |
Current Transfer Ratio (Min): | 50% @ 5mA |
Current Transfer Ratio (Max): | 600% @ 5mA |
Turn On / Turn Off Time (Typ): | 3µs, 3µs |
Rise / Fall Time (Typ): | 2µs, 3µs |
Input Type: | DC |
Output Type: | Transistor |
Voltage - Output (Max): | 55V |
Current - Output / Channel: | - |
Voltage - Forward (Vf) (Typ): | 1.15V |
Current - DC Forward (If) (Max): | 50 mA |
Vce Saturation (Max): | 400mV |
Operating Temperature: | -55°C ~ 100°C |
Mounting Type: | Through Hole |
Package / Case: | 8-DIP (0.300", 7.62mm) |
Supplier Device Package: | - |
