Type | Description |
---|---|
Series: | TDN 3WISM (3W) |
Package: | Tube |
Part Status: | Active |
Type: | Isolated Module |
Number of Outputs: | 2 |
Voltage - Input (Min): | 4.5V |
Voltage - Input (Max): | 18V |
Voltage - Output 1: | 5V |
Voltage - Output 2: | -5V |
Voltage - Output 3: | - |
Voltage - Output 4: | - |
Current - Output (Max): | 300mA, 300mA |
Power (Watts): | 3 W |
Voltage - Isolation: | 1.6 kV |
Applications: | ITE (Commercial) |
Features: | Remote On/Off, SCP |
Operating Temperature: | -40°C ~ 70°C |
Efficiency: | 80% |
Mounting Type: | Surface Mount |
Package / Case: | 7-SMD Module, 6 Leads |
Size / Dimension: | 0.52" L x 0.36" W x 0.40" H (13.2mm x 9.1mm x 10.2mm) |
Supplier Device Package: | - |
Control Features: | - |
Approval Agency: | - |
Standard Number: | - |
