Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of SMT-0540-S-2-R is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | SMT |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Driver Circuitry: | Transducer, Externally Driven |
Input Type: | Zero-Peak Signal |
Voltage - Rated: | 3 V |
Voltage Range: | 2 ~ 4V |
Frequency: | 4kHz |
Technology: | Electromechanical/Magnetic |
Operating Mode: | - |
Duration: | - |
Sound Pressure Level (SPL): | 75dB @ 3V, 10cm |
Current - Supply: | 100mA |
Port Location: | Side |
Operating Temperature: | -30°C ~ 70°C |
Approval Agency: | - |
Ratings: | - |
Ingress Protection: | - |
Mounting Type: | Surface Mount |
Termination: | Solder Pads |
Size / Dimension: | 0.197" L x 0.197" W (5.00mm x 5.00mm) |
Height - Seated (Max): | 0.087" (2.20mm) |
