Type | Description |
---|---|
Series: | X |
Package: | Box |
Part Status: | Active |
Driver Circuitry: | Indicator, Internally Driven |
Input Type: | DC |
Voltage - Rated: | 12 V |
Voltage Range: | 9 ~ 14V |
Frequency: | 2kHz ~ 3kHz |
Technology: | Electromechanical/Magnetic |
Operating Mode: | Single Tone |
Duration: | - |
Sound Pressure Level (SPL): | 107dB @ 12V, 10cm |
Current - Supply: | 70mA |
Port Location: | Top |
Operating Temperature: | -10°C ~ 60°C |
Approval Agency: | - |
Ratings: | Washable |
Ingress Protection: | - |
Mounting Type: | Through Hole |
Termination: | PC Pins |
Size / Dimension: | 0.984" Dia (25.00mm) |
Height - Seated (Max): | 0.898" (22.80mm) |
