Type | Description |
---|---|
Series: | MSS |
Package: | Bulk |
Part Status: | Active |
Driver Circuitry: | Indicator, Internally Driven |
Input Type: | DC |
Voltage - Rated: | 5 V |
Voltage Range: | 4.5 ~ 5.5V |
Frequency: | 2.075kHz |
Technology: | Magnetic |
Operating Mode: | Pin Selectable |
Duration: | Variable |
Sound Pressure Level (SPL): | 85dB @ 5V, 10cm |
Current - Supply: | 20 ~ 225mA |
Port Location: | Top |
Operating Temperature: | -30°C ~ 55°C |
Approval Agency: | cUL, UL |
Ratings: | Medical |
Ingress Protection: | - |
Mounting Type: | Through Hole |
Termination: | PC Pins |
Size / Dimension: | 0.906" L x 0.906" W (23.00mm x 23.00mm) |
Height - Seated (Max): | 0.539" (13.70mm) |
