Type | Description |
---|---|
Series: | AI |
Package: | Bulk |
Part Status: | Active |
Driver Circuitry: | Indicator, Internally Driven |
Input Type: | DC |
Voltage - Rated: | 24 V |
Voltage Range: | 1 ~ 28V |
Frequency: | 2.9kHz |
Technology: | Piezo |
Operating Mode: | Single Tone |
Duration: | - |
Sound Pressure Level (SPL): | 95dB @ 24V, 10cm |
Current - Supply: | 15mA |
Port Location: | Top |
Operating Temperature: | -20°C ~ 60°C |
Approval Agency: | - |
Ratings: | - |
Ingress Protection: | - |
Mounting Type: | Panel Mount |
Termination: | Solder Tabs |
Size / Dimension: | 1.654" Dia (42.00mm) |
Height - Seated (Max): | 0.827" (21.00mm) |
