Current price of HVMLS682M020EK0D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | MLS |
Package: | Bulk |
Part Status: | Active |
Capacitance: | 6800 µF |
Tolerance: | ±20% |
Voltage - Rated: | 20 V |
ESR (Equivalent Series Resistance): | 84mOhm @ 120Hz |
Lifetime @ Temp.: | 10000 Hrs @ 85°C |
Operating Temperature: | -55°C ~ 125°C |
Polarization: | Polar |
Ratings: | - |
Applications: | General Purpose |
Ripple Current @ Low Frequency: | 11 A @ 120 Hz |
Ripple Current @ High Frequency: | 12.2 A @ 20 kHz |
Impedance: | - |
Lead Spacing: | 1.000" (25.40mm) |
Size / Dimension: | 1.500" L x 1.750" W (38.10mm x 44.45mm) |
Height - Seated (Max): | 0.500" (12.70mm) |
Surface Mount Land Size: | - |
Mounting Type: | Chassis Mount |
Package / Case: | FlatPack, Tabbed |
RES 220 OHM 0.5% 1/10W 0603
CAP ALUM 6800UF 20% 20V FLATPACK
