BD540-30

Image is for reference,
please contact us to get the real picture

Part No :: BD540-30

Manufacturer: Wickmann / Littelfuse

Description: PTC RESET FUSE 16V 21A RADIAL

Catalog: PTC Resettable Fuses

Shipped from: HK warehouse

Expected Shipping Date: Aug 11 - Aug 15 2025

DataSheet: BD540-30 PDF

Availability: 0 pieces

Unit Price: ~~$7.06000~~

Current price of BD540-30 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

BD540-30 Specifications

Type	Description
Series:	PolySwitch®, BD540
Package:	Bulk
Part Status:	Active
Type:	Polymeric
Voltage - Max:	16V
Current - Max:	100 A
Current - Hold (Ih) (Max):	21 A
Current - Trip (It):	40 A
Time to Trip:	13 s
Resistance - Initial (Ri) (Min):	1.6 mOhms
Resistance - Post Trip (R1) (Max):	4.4 mOhms
Resistance - 25°C (Typ):	-
Operating Temperature:	-
Ratings:	-
Mounting Type:	Through Hole
Package / Case:	Radial, Disc
Size / Dimension:	0.987" L x 0.384" W (25.08mm x 9.75mm)
Height - Seated (Max):	0.880" (22.36mm)
Thickness (Max):	-
Lead Spacing:	0.392" (9.95mm)

Please confirm the specifications of the products when ordering.
