Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of EJ502B is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | - |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Jack |
Gender: | Male |
Industry Recognized Mating Diameter: | 2.50mm ID (0.098"), 5.50mm OD (0.217") |
Actual Diameter: | 0.098" (2.50mm ID), 0.220" (5.60mm OD) |
Number of Positions/Contacts: | 2 Conductors, 3 Contacts |
Internal Switch(s): | Single Switch, Normally Closed |
Mounting Type: | Chassis Mount |
Mounting Feature: | Bulkhead - Front Side Nut |
Termination: | Solder Eyelet(s) |
Shielding: | Unshielded |
Features: | - |
Insulation Color: | - |
Voltage - Rated: | 12VDC |
Current Rating (Amps): | 5 A |
Mating Length/Depth: | - |
Ingress Protection: | - |
Material Flammability Rating: | - |
