306-006-520-101

Image is for reference,
please contact us to get the real picture

Part No :: 306-006-520-101

Manufacturer: EDAC Inc.

Description: CONN EDGE DUAL FMALE 12POS 0.156

Catalog: Card Edge Connectors - Edgeboard Connectors

Shipped from: HK warehouse

Expected Shipping Date: Jul 01 - Jul 05 2025

DataSheet: 306-006-520-101 PDF

Availability: 0 pieces

Unit Price: ~~$6.59400~~

Current price of 306-006-520-101 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

306-006-520-101 Specifications

Type	Description
Series:	306
Package:	Bulk
Part Status:	Active
Card Type:	Non Specified - Dual Edge
Gender:	Female
Number of Positions/Bay/Row:	6
Number of Positions:	12
Card Thickness:	0.062" (1.57mm)
Number of Rows:	2
Pitch:	0.156" (3.96mm)
Read Out:	Single
Features:	-
Mounting Type:	Through Hole
Termination:	Solder
Contact Material:	Copper, Nickel, Tin Alloy
Contact Finish:	Gold
Contact Finish Thickness:	-
Contact Type:	-
Color:	Green
Flange Feature:	-
Operating Temperature:	-65°C ~ 125°C

Please confirm the specifications of the products when ordering.
