K86X-ED-15S-BR30

Image is for reference,
please contact us to get the real picture

Part No :: K86X-ED-15S-BR30

Manufacturer: Kycon

Description: CONN D-SUB HD RCPT 15P VERT SLDR

Catalog: D-Sub Connectors

Shipped from: HK warehouse

Expected Shipping Date: Jul 04 - Jul 08 2025

DataSheet: K86X-ED-15S-BR30 PDF

Availability: 0 pieces

Unit Price: ~~$3.35530~~

Current price of K86X-ED-15S-BR30 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

K86X-ED-15S-BR30 Specifications

Type	Description
Series:	K86X
Package:	Tray
Part Status:	Active
Connector Style:	D-Sub, High Density
Connector Type:	Receptacle, Female Sockets
Number of Positions:	15
Number of Rows:	3
Mounting Type:	Through Hole
Shell Size, Connector Layout:	1 (DE, E) High Density
Contact Type:	Signal
Flange Feature:	Board Side (4-40)
Termination:	Solder
Shell Material, Finish:	Steel, Nickel Plated
Contact Finish:	Gold
Contact Finish Thickness:	30.0µin (0.76µm)
Ingress Protection:	-
Material Flammability Rating:	UL94 V-0
Current Rating (Amps):	1.5A
Backset Spacing:	-
Features:	Board Lock

Please confirm the specifications of the products when ordering.
