Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of FTMH-120-02-F-DH-K-TR is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | FTMH |
Package: | Tape & Reel (TR) |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.039" (1.00mm) |
Number of Positions: | 40 |
Number of Rows: | 2 |
Row Spacing - Mating: | 0.039" (1.00mm) |
Number of Positions Loaded: | All |
Style: | Board to Board |
Shrouding: | Unshrouded |
Mounting Type: | Surface Mount, Right Angle |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Length - Mating: | 0.075" (1.90mm) |
Contact Length - Post: | - |
Overall Contact Length: | - |
Insulation Height: | 0.125" (3.18mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Gold |
Contact Finish Thickness - Mating: | 3.00µin (0.076µm) |
Contact Finish - Post: | Tin |
Contact Material: | Phosphor Bronze |
Insulation Material: | Liquid Crystal Polymer (LCP) |
Features: | Pick and Place |
Operating Temperature: | -55°C ~ 125°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-0 |
Insulation Color: | Black |
Current Rating (Amps): | 2.8A per Contact |
Voltage Rating: | - |
CONN HEADER SMD R/A 40POS 1MM
