Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 860-80-050-40-001101 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 860 |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.039" (1.00mm) |
Number of Positions: | 50 |
Number of Rows: | 1 |
Row Spacing - Mating: | - |
Number of Positions Loaded: | All |
Style: | Board to Board |
Shrouding: | Unshrouded |
Mounting Type: | Surface Mount, Right Angle |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Length - Mating: | 0.086" (2.20mm) |
Contact Length - Post: | - |
Overall Contact Length: | - |
Insulation Height: | 0.087" (2.20mm) |
Contact Shape: | Circular |
Contact Finish - Mating: | Tin |
Contact Finish Thickness - Mating: | - |
Contact Finish - Post: | Tin |
Contact Material: | Brass |
Insulation Material: | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled |
Features: | - |
Operating Temperature: | -55°C ~ 125°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-0 |
Insulation Color: | Black |
Current Rating (Amps): | 1A |
Voltage Rating: | 150VDC |
CAP CER 820PF 100V X7R 0603
CONN HEADER SMD R/A 50POS 1MM
