Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 399-10-141-10-009000 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 399 |
Package: | Bulk |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.100" (2.54mm) |
Number of Positions: | 41 |
Number of Rows: | 1 |
Row Spacing - Mating: | - |
Number of Positions Loaded: | All |
Style: | Board to Board |
Shrouding: | Unshrouded |
Mounting Type: | Through Hole, Right Angle |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Length - Mating: | 0.157" (4.00mm) |
Contact Length - Post: | 0.126" (3.20mm) |
Overall Contact Length: | - |
Insulation Height: | 0.100" (2.54mm) |
Contact Shape: | Circular |
Contact Finish - Mating: | Gold |
Contact Finish Thickness - Mating: | 10.0µin (0.25µm) |
Contact Finish - Post: | Gold |
Contact Material: | Brass Alloy |
Insulation Material: | Polycyclohexylenedimethylene Terephthalate (PCT) |
Features: | - |
Operating Temperature: | - |
Ingress Protection: | - |
Material Flammability Rating: | - |
Insulation Color: | Black |
Current Rating (Amps): | - |
Voltage Rating: | - |
