Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 3117-2-00-21-00-00-08-0 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 3117 |
Package: | Bulk |
Part Status: | Active |
Terminal Type: | PC Pin |
Terminal Style: | Single End |
Pin Size - Above Flange: | 0.024" (0.61mm) Dia |
Pin Size - Below Flange: | - |
Length - Above Flange: | 0.188" (4.78mm) |
Length - Below Flange: | 0.078" (1.98mm) |
Length - Overall: | 0.291" (7.39mm) |
Flange Diameter: | 0.060" (1.52mm) |
Mounting Hole Diameter: | 0.035" (0.89mm) |
Mounting Type: | Through Hole |
Termination: | Swage |
Insulation: | Non-Insulated |
Board Thickness: | 0.062" (1.57mm) |
Contact Material: | Brass Alloy |
Contact Finish: | Gold |
Contact Finish Thickness: | 20.0µin (0.51µm) |
