Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 1179-0-00-15-00-00-33-0 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 1179 |
Package: | Bulk |
Part Status: | Active |
Terminal Type: | PC Pin |
Terminal Style: | Single End, Nail Head |
Pin Size - Above Flange: | 0.040" (1.02mm) Dia |
Pin Size - Below Flange: | - |
Length - Above Flange: | 0.644" (16.36mm) |
Length - Below Flange: | - |
Length - Overall: | 0.664" (16.87mm) |
Flange Diameter: | 0.060" (1.52mm) |
Mounting Hole Diameter: | 0.044" (1.12mm) |
Mounting Type: | Through Hole |
Termination: | Solder |
Insulation: | Non-Insulated |
Board Thickness: | - |
Contact Material: | Brass Alloy |
Contact Finish: | Gold |
Contact Finish Thickness: | 10.0µin (0.25µm) |
