C5S-28.63636-10-1520-M

Image is for reference,
please contact us to get the real picture

Part No :: C5S-28.63636-10-1520-M

Manufacturer: Aker Technology USA

Description: CRYSTAL 28.63636MHZ 10PF SMD

Catalog: Crystals

Shipped from: HK warehouse

Expected Shipping Date: Jul 09 - Jul 13 2025

DataSheet: C5S-28.63636-10-1520-M PDF

Availability: 0 pieces

Unit Price: ~~$0.50000~~

Current price of C5S-28.63636-10-1520-M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

C5S-28.63636-10-1520-M Specifications

Type	Description
Series:	C5S
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	MHz Crystal
Frequency:	28.63636 MHz
Frequency Stability:	±20ppm
Frequency Tolerance:	±15ppm
Load Capacitance:	10pF
ESR (Equivalent Series Resistance):	40 Ohms
Operating Mode:	Fundamental
Operating Temperature:	-20°C ~ 70°C
Ratings:	-
Mounting Type:	Surface Mount
Package / Case:	4-SMD, No Lead
Size / Dimension:	0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max):	0.039" (1.00mm)
