Current price of BTS244ZE3043AKSA2 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | TEMPFET® |
Package: | Tube |
Part Status: | Active |
FET Type: | N-Channel |
Technology: | MOSFET (Metal Oxide) |
Drain to Source Voltage (Vdss): | 55 V |
Current - Continuous Drain (Id) @ 25°C: | 35A (Tc) |
Drive Voltage (Max Rds On, Min Rds On): | 4.5V, 10V |
Rds On (Max) @ Id, Vgs: | 13mOhm @ 19A, 10V |
Vgs(th) (Max) @ Id: | 2V @ 130µA |
Gate Charge (Qg) (Max) @ Vgs: | 130 nC @ 10 V |
Vgs (Max): | ±20V |
Input Capacitance (Ciss) (Max) @ Vds: | 2660 pF @ 25 V |
FET Feature: | Temperature Sensing Diode |
Power Dissipation (Max): | 170W (Tc) |
Operating Temperature: | -40°C ~ 175°C (TJ) |
Mounting Type: | Surface Mount |
Supplier Device Package: | PG-TO220-5-12 |
Package / Case: | TO-220-5 |
