Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of DMN2028USS-13 is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | - |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
FET Type: | N-Channel |
Technology: | MOSFET (Metal Oxide) |
Drain to Source Voltage (Vdss): | 20 V |
Current - Continuous Drain (Id) @ 25°C: | 7.3A (Ta) |
Drive Voltage (Max Rds On, Min Rds On): | 1.5V, 4.5V |
Rds On (Max) @ Id, Vgs: | 20mOhm @ 9.4A, 4.5V |
Vgs(th) (Max) @ Id: | 1.3V @ 250µA |
Gate Charge (Qg) (Max) @ Vgs: | 11.6 nC @ 4.5 V |
Vgs (Max): | ±8V |
Input Capacitance (Ciss) (Max) @ Vds: | 1000 pF @ 10 V |
FET Feature: | - |
Power Dissipation (Max): | 1.56W (Ta) |
Operating Temperature: | -55°C ~ 150°C (TJ) |
Mounting Type: | Surface Mount |
Supplier Device Package: | 8-SO |
Package / Case: | 8-SOIC (0.154", 3.90mm Width) |
MOSFET N-CH 20V 7.3A 8SO
