Type | Description |
---|---|
Series: | - |
Package: | Tube |
Part Status: | Active |
FET Type: | P-Channel |
Technology: | MOSFET (Metal Oxide) |
Drain to Source Voltage (Vdss): | 60 V |
Current - Continuous Drain (Id) @ 25°C: | 11A (Tc) |
Drive Voltage (Max Rds On, Min Rds On): | 10V |
Rds On (Max) @ Id, Vgs: | 280mOhm @ 6.6A, 10V |
Vgs(th) (Max) @ Id: | 4V @ 250µA |
Gate Charge (Qg) (Max) @ Vgs: | 19 nC @ 10 V |
Vgs (Max): | ±20V |
Input Capacitance (Ciss) (Max) @ Vds: | 570 pF @ 25 V |
FET Feature: | - |
Power Dissipation (Max): | 60W (Tc) |
Operating Temperature: | -55°C ~ 175°C (TJ) |
Mounting Type: | Through Hole |
Supplier Device Package: | TO-220AB |
Package / Case: | TO-220-3 |
RES ARRAY 2 RES 3 OHM 0404
CAP MICA 120PF 50V RADIAL
CAP THIN FILM 1PF 50V 0805
MOSFET P-CH 60V 11A TO220AB
