Current price of OD4010-24MSS02A is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | OD4010 |
Package: | Bulk |
Part Status: | Active |
Voltage - Rated: | 24VDC |
Size / Dimension: | Square - 40mm L x 40mm H |
Width: | 10.50mm |
Air Flow: | 6.0 CFM (0.168m³/min) |
Static Pressure: | 0.080 in H2O (19.9 Pa) |
Bearing Type: | Sealed Sleeve |
Fan Type: | Tubeaxial |
Features: | Locked Rotor Sensor |
Noise: | 20.0dB |
Power (Watts): | - |
RPM: | 4800 RPM |
Termination: | 3 Wire Leads |
Ingress Protection: | - |
Operating Temperature: | -4 ~ 176°F (-20 ~ 80°C) |
Approval Agency: | cURus, TUV |
Weight: | - |
