B82720H0015A028

Image is for reference,
please contact us to get the real picture

Part No :: B82720H0015A028

Manufacturer: TDK EPCOS

Description: CMC 28MH 400MA 2LN TH

Catalog: Common Mode Chokes

Shipped from: HK warehouse

Expected Shipping Date: Jul 28 - Aug 01 2025

DataSheet: B82720H0015A028 PDF

Availability: 0 pieces

Unit Price: ~~$1.52628~~

Current price of B82720H0015A028 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

B82720H0015A028 Specifications

Type	Description
Series:	B82720
Package:	Tray
Part Status:	Active
Filter Type:	Signal Line
Number of Lines:	2
Impedance @ Frequency:	-
Inductance @ Frequency:	28 mH @ 10 kHz
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	400mA
DC Resistance (DCR) (Max):	1.2Ohm (Typ)
Voltage Rating - DC:	80V
Voltage Rating - AC:	42V
Operating Temperature:	-40°C ~ 125°C
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Through Hole
Size / Dimension:	0.512" L x 0.374" W (13.00mm x 9.50mm)
Height (Max):	0.551" (14.00mm)
Package / Case:	Vertical, 4 PC Pin

Please confirm the specifications of the products when ordering.
