SRF1260A-820M

Image is for reference,
please contact us to get the real picture

Part No :: SRF1260A-820M

Manufacturer: J.W. Miller / Bourns

Description: INDUCT ARRAY 2 COIL 82UH SMD

Catalog: Arrays, Signal Transformers

Shipped from: HK warehouse

Expected Shipping Date: Jul 01 - Jul 05 2025

DataSheet: SRF1260A-820M PDF

Availability: 0 pieces

Unit Price: ~~$0.71760~~

Current price of SRF1260A-820M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

SRF1260A-820M Specifications

Type	Description
Series:	SRF1260A
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	82 µH
Inductance - Connected In Series:	328 µH
Tolerance:	±20%
Current Rating - Parallel:	2.05 A
Current Rating - Series:	1.03 A
Current Saturation - Parallel:	2.39 A
Current Saturation - Series:	1.2 A
DC Resistance (DCR) - Parallel:	150mOhm Max
DC Resistance (DCR) - Series:	568mOhm Max
Shielding:	Shielded
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.492" L x 0.492" W (12.50mm x 12.50mm)
Height:	0.244" (6.20mm)

Please confirm the specifications of the products when ordering.
