SRF0703A-8R2M

SRF0703A-8R2M

Image is for reference,
please contact us to get the real picture

Part No :

SRF0703A-8R2M

Manufacturer
J.W. Miller / Bourns
Description
INDUCT ARRAY 2 COIL 8.2UH SMD
Catalog
Arrays, Signal Transformers
Shipped from
HK warehouse
Expected Shipping Date
Jun 30 - Jul 04 2025
DataSheet
SRF0703A-8R2M PDF
Availability
43 pieces
Unit Price
$1.17000

Current price of SRF0703A-8R2M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

SRF0703A-8R2M Specifications
Type Description
Series:SRF0703A
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Number of Coils:2
Inductance - Connected In Parallel:8.2 µH
Inductance - Connected In Series:34.1 µH
Tolerance:±20%
Current Rating - Parallel:2.19 A
Current Rating - Series:1.1 A
Current Saturation - Parallel:2.66 A
Current Saturation - Series:1.33 A
DC Resistance (DCR) - Parallel:77.2mOhm Max
DC Resistance (DCR) - Series:306mOhm Max
Shielding:Shielded
Ratings:AEC-Q200
Operating Temperature:-40°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:Nonstandard
Size / Dimension:0.299" L x 0.299" W (7.60mm x 7.60mm)
Height:0.142" (3.60mm)
