P0396NL

P0396NL

Image is for reference,
please contact us to get the real picture

Part No :

P0396NL

Manufacturer
PulseLarsen Antenna
Description
INDUCT ARRAY 2 COIL 3.5UH SMD
Catalog
Arrays, Signal Transformers
Shipped from
HK warehouse
Expected Shipping Date
Jul 01 - Jul 05 2025
DataSheet
P0396NL PDF
Availability
0 pieces
Unit Price
$2.83000

Current price of P0396NL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

P0396NL Specifications
Type Description
Series:Tomcat
Package:Tube
Part Status:Active
Number of Coils:2
Inductance - Connected In Parallel:3.5 µH
Inductance - Connected In Series:14 µH
Tolerance:±20%
Current Rating - Parallel:11.2 A
Current Rating - Series:5.6 A
Current Saturation - Parallel:-
Current Saturation - Series:-
DC Resistance (DCR) - Parallel:6.54mOhm
DC Resistance (DCR) - Series:26.2mOhm
Shielding:Unshielded
Ratings:-
Operating Temperature:-40°C ~ 130°C
Mounting Type:Surface Mount
Package / Case:Nonstandard
Size / Dimension:0.715" L x 0.590" W (18.16mm x 14.99mm)
Height:0.310" (7.87mm)
