PF0553.824NL

PF0553.824NL

Image is for reference,
please contact us to get the real picture

Part No :

PF0553.824NL

Manufacturer
PulseLarsen Antenna
Description
INDUCT ARRAY 2 COIL 830UH SMD
Catalog
Arrays, Signal Transformers
Shipped from
HK warehouse
Expected Shipping Date
Jul 03 - Jul 07 2025
DataSheet
PF0553.824NL PDF
Availability
0 pieces
Unit Price
$2.02000

Current price of PF0553.824NL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PF0553.824NL Specifications
Type Description
Series:PF0553NL
Package:Tray
Part Status:Active
Number of Coils:2
Inductance - Connected In Parallel:830 µH
Inductance - Connected In Series:3.3 mH
Tolerance:±20%
Current Rating - Parallel:640 mA
Current Rating - Series:320 mA
Current Saturation - Parallel:1.3 A
Current Saturation - Series:630 mA
DC Resistance (DCR) - Parallel:1.4Ohm Max
DC Resistance (DCR) - Series:5.8Ohm Max
Shielding:Shielded
Ratings:-
Operating Temperature:-40°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:Nonstandard
Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
Height:0.343" (8.71mm)
