Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of PA4546.332NLT is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | PA4546.XXXNLT |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Molded |
Material - Core: | - |
Inductance: | 3.3 µH |
Tolerance: | ±20% |
Current Rating (Amps): | 2.3 A |
Current - Saturation (Isat): | 3A |
Shielding: | Unshielded |
DC Resistance (DCR): | 97mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | - |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 100 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | - |
Size / Dimension: | 0.175" L x 0.160" W (4.45mm x 4.06mm) |
Height - Seated (Max): | 0.047" (1.20mm) |
