LGJ12565TS-102MR45-H

Image is for reference,
please contact us to get the real picture

Part No :: LGJ12565TS-102MR45-H

Manufacturer: TDK Corporation

Description: FIXED IND 1MH 500MA 1.68 OHM SMD

Catalog: Fixed Inductors

Shipped from: HK warehouse

Expected Shipping Date: Jul 29 - Aug 02 2025

DataSheet: LGJ12565TS-102MR45-H PDF

Availability: 470 pieces

Unit Price: ~~$6.60000~~

Current price of LGJ12565TS-102MR45-H is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

LGJ12565TS-102MR45-H Specifications

Type	Description
Series:	LGJ
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	1 mH
Tolerance:	±20%
Current Rating (Amps):	500 mA
Current - Saturation (Isat):	450mA
Shielding:	Shielded
DC Resistance (DCR):	1.68Ohm
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max):	0.256" (6.50mm)
