PM0603-2N2-RC

PM0603-2N2-RC

Image is for reference,
please contact us to get the real picture

Part No :

PM0603-2N2-RC

Manufacturer
J.W. Miller / Bourns
Description
FIXED IND 2.2NH 700MA 80MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Aug 01 - Aug 05 2025
DataSheet
PM0603-2N2-RC PDF
Availability
0 pieces
Unit Price
$0.13260

Current price of PM0603-2N2-RC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PM0603-2N2-RC Specifications
Type Description
Series:PM0603
Package:Tape & Reel (TR)
Part Status:Active
Type:Wirewound
Material - Core:Alumina
Inductance:2.2 nH
Tolerance:±0.3nH
Current Rating (Amps):700 mA
Current - Saturation (Isat):-
Shielding:Unshielded
DC Resistance (DCR):80mOhm
Q @ Freq:16 @ 250MHz
Frequency - Self Resonant:6GHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:250 MHz
Features:-
Mounting Type:Surface Mount
Package / Case:0603 (1608 Metric)
Supplier Device Package:0603 (1608 Metric)
Size / Dimension:0.065" L x 0.041" W (1.65mm x 1.05mm)
Height - Seated (Max):0.047" (1.20mm)
