Due to the large price fluctuation in 2021-2022, please send an inquiry to get the latest quotation, The current price of 4590R-125K is for reference only, if you want to get the best price, please submit an inquiry or email directly to our sales team [email protected]
Type | Description |
---|---|
Series: | 4590R |
Package: | Bulk |
Part Status: | Active |
Type: | Wirewound |
Material - Core: | Ferrite |
Inductance: | 1.2 mH |
Tolerance: | ±10% |
Current Rating (Amps): | 825 mA |
Current - Saturation (Isat): | 510mA |
Shielding: | Unshielded |
DC Resistance (DCR): | 977mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | - |
Ratings: | - |
Operating Temperature: | -55°C ~ 125°C |
Inductance Frequency - Test: | 1 kHz |
Features: | - |
Mounting Type: | Through Hole |
Package / Case: | Axial |
Supplier Device Package: | - |
Size / Dimension: | 0.455" Dia x 0.900" L (11.55mm x 22.86mm) |
Height - Seated (Max): | - |
