4922-22L

Image is for reference,
please contact us to get the real picture

Part No :: 4922-22L

Manufacturer: API Delevan

Description: FIXED IND 56UH 1A 397 MOHM SMD

Catalog: Fixed Inductors

Shipped from: HK warehouse

Expected Shipping Date: Jul 10 - Jul 14 2025

DataSheet: 4922-22L PDF

Availability: 0 pieces

Unit Price: ~~$1.90185~~

Current price of 4922-22L is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

4922-22L Specifications

Type	Description
Series:	4922
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	56 µH
Tolerance:	±15%
Current Rating (Amps):	1 A
Current - Saturation (Isat):	1A
Shielding:	Unshielded
DC Resistance (DCR):	397mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.505" L x 0.240" W (12.82mm x 6.09mm)
Height - Seated (Max):	0.230" (5.84mm)

Please confirm the specifications of the products when ordering.
