PM1608-220M-RC

PM1608-220M-RC

Image is for reference,
please contact us to get the real picture

Part No :

PM1608-220M-RC

Manufacturer
J.W. Miller / Bourns
Description
FIXED IND 22UH 800MA 370MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Jul 18 - Jul 22 2025
DataSheet
PM1608-220M-RC PDF
Availability
0 pieces
Unit Price
$0.63000

Current price of PM1608-220M-RC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PM1608-220M-RC Specifications
Type Description
Series:PM1608
Package:Tape & Reel (TR)
Part Status:Active
Type:Wirewound
Material - Core:Ferrite
Inductance:22 µH
Tolerance:±20%
Current Rating (Amps):800 mA
Current - Saturation (Isat):700mA
Shielding:Unshielded
DC Resistance (DCR):370mOhm Max
Q @ Freq:16 @ 2.52MHz
Frequency - Self Resonant:20MHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:2.52 MHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max):0.115" (2.92mm)
