Current price of EST1040T1R0NDGA is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | ES, T Type |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Wirewound |
Material - Core: | Ferrite |
Inductance: | 1 µH |
Tolerance: | ±30% |
Current Rating (Amps): | 3.6 A |
Current - Saturation (Isat): | 10.7A |
Shielding: | Shielded |
DC Resistance (DCR): | 10mOhm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | 104MHz |
Ratings: | AEC-Q200 |
Operating Temperature: | -55°C ~ 150°C |
Inductance Frequency - Test: | 100 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | - |
Size / Dimension: | 0.398" L x 0.394" W (10.10mm x 10.00mm) |
Height - Seated (Max): | 0.169" (4.30mm) |
