PA2247.103NLT

PA2247.103NLT

Image is for reference,
please contact us to get the real picture

Part No :

PA2247.103NLT

Manufacturer
PulseLarsen Antenna
Description
FIXED IND 10UH 24A 8.6MOHM SMD
Catalog
Fixed Inductors
Shipped from
HK warehouse
Expected Shipping Date
Aug 09 - Aug 13 2025
DataSheet
PA2247.103NLT PDF
Availability
638 pieces
Unit Price
$6.79000

Current price of PA2247.103NLT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PA2247.103NLT Specifications
Type Description
Series:PA2247.XXXNLT
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Type:-
Material - Core:-
Inductance:10 µH
Tolerance:±20%
Current Rating (Amps):24 A
Current - Saturation (Isat):26A
Shielding:Unshielded
DC Resistance (DCR):8.6mOhm Max
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:-
Operating Temperature:-55°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.650" L x 0.610" W (16.50mm x 15.50mm)
Height - Seated (Max):0.394" (10.00mm)
