SDE0403A-2R2M

Image is for reference,
please contact us to get the real picture

Part No :: SDE0403A-2R2M

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 2.2UH 2.3A 71 MOHM SMD

Catalog: Fixed Inductors

Shipped from: HK warehouse

Expected Shipping Date: Aug 06 - Aug 10 2025

DataSheet: SDE0403A-2R2M PDF

Availability: 915 pieces

Unit Price: ~~$0.68000~~

Current price of SDE0403A-2R2M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

SDE0403A-2R2M Specifications

Type	Description
Series:	SDE0403A
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	2.2 µH
Tolerance:	±20%
Current Rating (Amps):	2.3 A
Current - Saturation (Isat):	3.3A
Shielding:	Unshielded
DC Resistance (DCR):	71mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	76MHz
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max):	0.138" (3.50mm)

Please confirm the specifications of the products when ordering.
