PM42S-820-RC

Image is for reference,
please contact us to get the real picture

Part No :: PM42S-820-RC

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 82UH 430MA 1.2 OHM SMD

Catalog: Fixed Inductors

Shipped from: HK warehouse

Expected Shipping Date: Jul 30 - Aug 03 2025

DataSheet: PM42S-820-RC PDF

Availability: 0 pieces

Unit Price: ~~$0.70400~~

Current price of PM42S-820-RC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PM42S-820-RC Specifications

Type	Description
Series:	PM42S
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	82 µH
Tolerance:	±30%
Current Rating (Amps):	430 mA
Current - Saturation (Isat):	320mA
Shielding:	Shielded
DC Resistance (DCR):	1.2Ohm Max
Q @ Freq:	8 @ 2.52MHz
Frequency - Self Resonant:	13MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max):	0.118" (3.00mm)
