Current price of SDR0403-101KL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | SDR0403 |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Type: | Wirewound |
Material - Core: | Ferrite |
Inductance: | 100 µH |
Tolerance: | ±10% |
Current Rating (Amps): | 350 mA |
Current - Saturation (Isat): | 510mA |
Shielding: | Unshielded |
DC Resistance (DCR): | 1.9Ohm Max |
Q @ Freq: | 35 @ 796kHz |
Frequency - Self Resonant: | 9MHz |
Ratings: | - |
Operating Temperature: | -40°C ~ 125°C |
Inductance Frequency - Test: | 1 kHz |
Features: | - |
Mounting Type: | Surface Mount |
Package / Case: | Nonstandard |
Supplier Device Package: | - |
Size / Dimension: | 0.177" L x 0.157" W (4.50mm x 4.00mm) |
Height - Seated (Max): | 0.138" (3.50mm) |
